Parameter: Type: Analog Output Module
Signal Specification: AO: 4…20mA or 1…+5 VDC
Number of Channels: 16 independently configurable AO channels
Power Requirements: 24 VDC±10%, typical 100 mA, maximum 125 mA
Dimensions: Standard (190 mm)
Installation Method: Horizontal or vertical
Maximum Field Cable Length: 600 meters (1968 feet)
D/A Resolution: 12 bits
Accuracy: FSR±0.01%FSR, FSR=25 mA or 6.25 VDC
Other Features: Electrical isolation (1500 V, max. 1 minute), channel isolation (1×16 group isolation, 1500 V, max. 1 minute)12.
The AO02 is an analog output module from ABB, serving as a key component of the ABB Ability™ Symphony®Plus hardware system. This module is specifically designed to handle advanced analog output field signals and boasts various advanced features such as HART support, configurable output channels, and robust protection mechanisms.
Specifications:
Type: Analog Output Module Signal Specification: AO: 4…20mA or 1…+5 VDC Number of Channels: 16 independently configurable AO channels Power Requirements: 24 VDC±10%, typical 100 mA, maximum 125 mA Dimensions: Standard (190 mm) Installation Method: Horizontal or vertical Maximum Field Cable Length: 600 meters (1968 feet) D/A Resolution: 12 bits Accuracy: FSR±0.01%FSR, FSR=25 mA or 6.25 VDC Other Features: Electrical isolation (1500 V, max. 1 minute), channel isolation (1×16 group isolation, 1500 V, max. 1 minute)12.
Functional Characteristics:
Efficient Digital Signal Processing: Able to respond quickly to the need to read sensor data or control actuators, ensuring real-time and accuracy in industrial automation systems4. Flexible Configuration and Programming: Users can adjust the module’s parameters and functions based on specific application requirements, making it adaptable to various industrial automation scenarios3. Robust Protection Mechanisms: Features safety functions such as short-circuit protection and open-circuit detection to ensure stable device operation1.
Application Fields: The AO02 analog output module is widely used in various industrial sectors, including but not limited to automotive manufacturing, electronics, food and beverage production, pharmaceutical manufacturing, logistics, and warehousing. It can be used for automated tasks such as assembly, welding, spraying, handling, packaging, and robot-assisted operations
