Model：ABB HBFFAEAGNBA1BAA11G

Brand: ABB 2025-09-04
Price range (USD): 2000-4000
Country: Sweden
Parameter: Product Line: Tmax XT

Frame Size: XT4 (630A Frame)

Breaking Capacity: N (50 kA at 415V AC)

Rated Current: 630 A

Contact Me

ABB HBFFAEAGNBA1BAA11G

Summary: Product Identification

Product Line: Tmax XT

Frame Size: XT4 (630A Frame)

Breaking Capacity: N (50 kA at 415V AC)

Rated Current: 630 A

Poles: 3

Trip Unit: PR332-EL (Electronic, Protection functions + Measurement + Communication ready)

Terminals: Front Terminals (standard direction)

Additional Features: Fixed Version, Spring Charging Motor, Extended Rating Plug, Grey Color

Detailed Technical Parameter Breakdown

Here is what each segment of the code (H B F F A E A G N B A1 B A A 11 G) means:

Segment	Code Letter	Meaning	Technical Parameter Description
1	H	Product Line	Tmax XT circuit breaker
2	B	Breaking Capacity	N (50 kA Icu at 415V AC)
3	F	Number of Poles & Protected Poles	4P 3d (4 poles, 3 protected with neutral)
4	F	Rated Current (In)	630 A (Frame size XT4)
5	A	Operating Mechanism	Fixed Version (Not withdrawable)
6	E	Terminal Type & Direction	Front terminals, standard cable entry direction
7	A	Release Type	Electronic Trip Unit (PR332)
8	G	Trip Unit Version	PR332-EL (Includes protection, energy measurement, and communication-ready via an add-on module)
9	N	Auxiliary Contacts	2 NO (Normally Open) + 2 NC (Normally Closed)
10	B	Shunt Trip / Under-voltage Release	Without shunt trip or UV release
11	A1	Additional Accessories	Spring Charging Motor (for remote/automatic closing)
12	B	Rating Plug	Extended Rating Plug (allows setting the In lower than the frame rating)
13	A	Terminal Shields	Without insulated terminal shields
14	A	Phase Barriers	Without phase barriers
15	11	Control Unit Interface	Standard rotary handle with "ON"/"OFF"/"TRIPPED" indication
16	G	Color	Light Grey (RAL 7035)

Key Technical Specifications (Compiled)

Rated Ultimate Breaking Capacity (Icu): 50 kA at 400/415V AC (IEC 60947-2)

Rated Operational Current (Ie): 630 A (Adjustable via the rating plug)

Rated Insulation Voltage (Ui): 1000 V

Rated Operational Voltage (Ue): 690 V AC

Number of Poles: 4 Poles (3 Phase + 1 Neutral, with the neutral unprotected)

Trip Unit: PR332-EL
