ABB 5SHX1960L0006 3BHB016120R0002 Module Overview

The ABB 5SHX1960L0006 3BHB016120R0002 is a module manufactured by ABB. Below are the detailed specifications and features of this module:

Basic Function:

This module is an Integrated Gate-Commutated Thyristor (IGCT) module designed for use in industrial automation and control systems, especially in applications requiring high reliability and high performance. It provides accurate and reliable drive signals while also offering protection and fault detection for IGBT devices.

Technical Specifications:


Input Voltage Range: 15 VDC to 30 VDC

Output Current Range: ±20 mA to ±1 A

Drive Voltage Range: 10 V to 20 V

Maximum Operating Temperature: +105°C

Maximum Storage Temperature: +125°C

Operating Humidity Range: 10% to 90% RH

Storage Humidity Range: 5% to 90% RH

Enclosure Material: Fiberglass-reinforced epoxy resin

Enclosure Dimensions: 67.5 mm x 31 mm x 16.5 mm

Weight: Approximately 530 grams

Application Fields:

This module is widely used in power electronics systems such as inverters, motor drives, uninterruptible power supplies (UPS), solar and wind power generation systems, and more.

Conclusion:

The ABB 5SHX1960L0006 3BHB016120R0002 is a high-performance and highly reliable IGCT module suitable for various industrial automation and power electronic system applications.
