Sweden The ABB DSDO115K12 (3BSE019933R1) is a high-performance digital output module designed for industrial automation applications. This module is part of ABB's extensive range of control system components, offering reliable operation in demanding environments.
The DSDO115K12 is a 16-channel digital output module that provides isolated switching capability for industrial control systems. It's designed for integration with ABB's AC 800M controller family and other compatible systems.
| Parameter | Specification |
|---|---|
| Product Code | DSDO115K12 |
| Order Number | 3BSE019933R1 |
| Type | Digital Output Module |
| Number of Channels | 16 |
| Output Type | Electromechanical relay |
| Contact Rating | 2A @ 230V AC/30V DC |
| Isolation Voltage | 1500V AC (channel to channel and channel to system) |
| Response Time | <10ms |
| Operating Voltage | 24V DC nominal (18-30V DC range) |
| Power Consumption | Typically 3W |
| Operating Temperature | -20°C to +70°C (-4°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Vibration Resistance | 5-8Hz: 3.5mm amplitude, 8-500Hz: 9.8m/s² acceleration |
| Shock Resistance | 147m/s² (15g), 11ms duration |
| MTBF | 500,000 hours |
| Dimensions (H x W x D) | 128 x 55 x 119 mm (5.04 x 2.17 x 4.69 in) |
| Weight | Approx. 0.5 kg (1.1 lb) |
| Certifications | CE, UL, ATEX (for hazardous areas) |
The DSDO115K12 module is designed for DIN rail mounting in standard control cabinets. The module features removable screw terminal blocks for easy wiring and maintenance. Each channel is clearly labeled for proper connection.
This digital output module is compatible with:
When ordering, please specify the complete product code: DSDO115K12 3BSE019933R1. For replacement parts or accessories, consult the ABB product catalog or contact your local ABB representative.
Installation and maintenance should only be performed by qualified personnel. Always follow local electrical codes and safety regulations. Disconnect power before working on the module or connected equipment.
For the most current technical information, always refer to the official ABB documentation or website.
