Sweden This model is a digital, multi-function, DIN-rail mounted time relay known for its versatility and reliability in industrial control applications.
| Parameter Category | Specification |
|---|---|
| Model Number | PHARPS32000000 (Often listed as part of the PS series, e.g., 1SVR730220R0200) |
| Product Line | ABB PS (Programmable & Multi-function Timer) |
| Supply Voltage | 24 - 240V AC/DC (Wide range, auto-sensing) |
| Time Ranges | 8 Ranges selectable via DIP-switches: • 0.05s - 0.5s • 0.1s - 1s • 0.5s - 5s • 1s - 10s • 5s - 50s • 10s - 100s • 1m - 10m • 5m - 50m |
| Functions (Modes) | 7 Standard Functions: 1. On-delay (A) 2. Off-delay (B) 3. On/Off-delay (C) 4. Flicker ON / Start-up (E) 5. Interval (F) 6. Asymmetrical flasher (G) 7. Symmetrical flasher (H) |
| Number of Outputs | 1 Changeover Relay (CO) - SPDT (1 NO + 1 NC) |
| Output Contact Rating | 8 A / 250 V AC (Resistive load) 5 A / 250 V AC (AC-15) 5 A / 30 V DC (DC-13) |
| Repeat Accuracy | < ±1% of set value + 20 ms |
| Reset Time | < 50 ms |
| Power Consumption | Approx. 2.5 VA (AC) / 1.5 W (DC) |
| Mounting | DIN Rail (35 mm) |
| Connection | Screw-clamp terminals |
| Degree of Protection | IP40 (Front panel) IP20 (Terminal area) |
| Operating Temperature | -20°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Standards & Approvals | CE, cULus Listed (UL 508 & CSA C22.2 No. 14), GL, RoHS, REACH |
| Electrical Life | > 1,000,000 operations (at rated load) |
| Mechanical Life | > 10,000,000 operations |
Wide Voltage Range (24-240V AC/DC): This is one of its most significant advantages. It can be used in virtually any standard control circuit worldwide without needing a separate power supply, making it incredibly versatile for machine builders and panel builders.
Multi-Function (7 Modes): Instead of buying a dedicated timer for each function, this single device can be configured for seven different timing operations. This reduces inventory and increases flexibility. The required function is selected using a rotary switch on the front.
Adjustable Time Range: The eight DIP-switch selectable ranges allow for both very short, precise delays (0.05s) and longer process delays (50 minutes). The exact time within the selected range is then finely adjusted using the potentiometer on the front.
Robust Output Relay: The 8A relay output is powerful enough to directly control contactors, solenoid valves, small motors, and other actuators, eliminating the need for an intermediate relay in many applications.
Clear Status Indication: It features a red LED that indicates the status of the output relay, providing immediate visual feedback for troubleshooting.
This timer is used across all industries for automation and control tasks, such as:
Sequencing motor start-ups (e.g., star-delta starting).
Controlling conveyor belt operations.
Automating filling or packaging machines.
Delaying the operation of fans, pumps, or lighting.
Creating flashing signals or warning lights.
Inventory//Affordable prices//Excellent quality//Imported with original packaging
===================================================================================================================================================================
First hand source//affordable price//Spot inventory!
•Shipping Port: Xiamen
•Manager: Rhonda•E-mail: sales7@saulplc.com
•Tel/WhatsApp/Wechat: + 86-15359273796
•Ship to you via Fedex/DHL/TNT/UPS/EMS
•Package: Original packing with cartons
