Sweden The DSDP170K02 is a 12.1-inch TFT color display station designed for industrial environments. It serves as the primary human-machine interface (HMI) for operators to monitor and control processes. It is part of the AC 800M and Freelance controller ecosystems.
| Parameter Category | Specification |
|---|---|
| Manufacturer / Model | ABB / DSDP170K02 |
| Ordering Code / Article Number | 3BSE019925R1 |
| Product Line | ABB Ability™ / Freelance / S800 I/O |
| Display Type | High-Resolution TFT Color LCD |
| Display Size | 12.1 inches (diagonal) |
| Resolution | 800 x 600 pixels (SVGA) |
| Touchscreen | Yes, Analog Resistive |
| Brightness | Typically ~400 cd/m² (very bright for plant floor visibility) |
| CPU (Processor) | Industrial-grade, often based on Intel architecture (exact model is proprietary but robust). |
| Memory (RAM) | Significant onboard memory for smooth operation of the HMI software (exact size is proprietary). |
| Flash Storage | Integrated for the operating system and application software. |
| Operating System | A proprietary, hardened, real-time operating system specific to ABB, ensuring high reliability and security. |
| Communication Protocols | Ethernet (TCP/IP) for integration with controllers (e.g., AC 800M). Serial ports (RS-232/RS-485) for legacy devices or peripherals. |
| Controller Integration | Native and seamless integration with: • ABB AC 800M High Performance Controller • ABB Freelance DCS Controllers |
| Software | Configured and programmed using ABB's Control Builder™ or Freelance Engineering software suites. |
| Front Panel Rating | IP65 / NEMA 4 (when properly installed and sealed). This means it is dust-tight and protected against low-pressure water jets, making it suitable for harsh industrial environments. |
| Mounting | Panel-mounted (requires cutout). Available in various mounting kits for different panel thicknesses. |
| Power Supply | 24 V DC (standard for industrial control systems). Typical range: 19.2 - 30 V DC. |
| Dimensions (W x H x D) | Approximately 321 x 259 x 57 mm (varies slightly with bezel and mounting) |
| Weight | Approximately 3.5 kg |
| Approvals | Typically carries standard industrial certifications like CE, ATEX, and others for use in hazardous areas (specific approvals depend on the market order). |
Robust Industrial Design: Built to operate reliably in environments with extreme temperatures, humidity, vibration, and electrical noise.
Integrated HMI: It's not just a monitor; it's a complete computer running the HMI application directly, eliminating the need for a separate PC.
Seamless Integration: Works flawlessly with ABB's AC 800M and Freelance controllers, allowing for direct tag-based communication for efficient engineering.
Visualization: Provides high-quality graphics for process mimic diagrams, trends, alarm summaries, and control faceplates.
Redundancy Support: Can be part of a redundant system configuration for critical processes where high availability is required.
The DSDP170K02 is used across a wide range of industries for process control and supervision, including:
Oil & Gas
Chemical & Pharmaceutical
Power Generation & Water/Wastewater
Pulp & Paper
Marine (e.g., vessel control systems)
Inventory//Affordable prices//Excellent quality//Imported with original packaging
===================================================================================================================================================================
First hand source//affordable price//Spot inventory!
•Shipping Port: Xiamen
•Manager: Rhonda•E-mail: sales7@saulplc.com
•Tel/WhatsApp/Wechat: + 86-15359273796
•Ship to you via Fedex/DHL/TNT/UPS/EMS
•Package: Original packing with cartons
