ABB GFD563A101 3BHE046836R0101

ABB GFD563A101 3BHE046836R0101 is an industrial automation module manufactured by ABB, widely used in industrial automation, control systems, and power control. Below is a detailed description of its technical specifications and functions:

1. Product Overview

ABB GFD563A101 3BHE046836R0101 is a modular control unit within the ABB AC 800PEC series, classified as an excitation control unit. It is applicable in industrial automation, power generation, marine, and oil & gas production. This module features high reliability, advanced technology, and modular design, making it easy to maintain and expand.

2. Main Functions

• Excitation Control: Used for measurement of generator voltage, current, and power, receiving status signals from protective relays, and managing generator excitation control and alarm indication.

• Protection Functions: Provides multiple protection features, including overcurrent, overvoltage, and undervoltage, ensuring safe equipment operation.

• Communication Functions: Supports multiple communication protocols such as Modbus, Profibus, CANopen, and Ethernet, enabling seamless integration with host computers, PLCs, and other devices.

• Modular Design: Modular structure facilitates easy maintenance and expansion, suitable for a variety of industrial automation applications.

3. Technical Specifications

General Parameters

• Model: GFD563A101 3BHE046836R0101

• Brand: ABB

• Origin: Switzerland

• Type: Excitation control unit or digital input/output module

Electrical Parameters

• Input Voltage: 24V DC

• Output Voltage: 0–10V DC

• Rated Current: 5A

• Operating Temperature Range: -20°C to +60°C

• Storage Temperature Range: -25°C to +85°C

• Humidity Range: 5–95% RH

• Protection Class: IP54

Physical Parameters

• Dimensions: 250mm × 245mm × 245mm

• Weight: approx. 0.92 kg

• Housing Material: Aluminum alloy

Communication & Interfaces

• Supported Protocols: Modbus, Profibus, Ethernet, RS485, etc.

• I/O Interfaces: Digital input/output, analog input/output

4. Application Scenarios

This module is widely applied in industrial automation, power generation, marine, and oil & gas production, for controlling and monitoring industrial processes, enhancing production efficiency and system reliability.

5. Summary

ABB GFD563A101 3BHE046836R0101 is a high-performance industrial automation module offering comprehensive functions and flexible configuration options. Its technical specifications and features make it a key component in industrial automation and power control applications.

===================================================================================================================================================================

First hand source//affordable price//Spot inventory!

•Shipping Port: Xiamen

•E-mail: sales7@saulplc.com

•Tel/WhatsApp/Wechat: + 86-15359273796

•Ship to you via Fedex/DHL/TNT/UPS/EMS

•Package: Original packing with cartons
