ABB PP845 (Part No. 3BSE042235R1) Technical Specifications Overview
Model: PP845
Part Number: 3BSE042235R1
Application Range: Signal processing, control, and monitoring in industrial automation (compliant with IEC 61131-2 standard)
| Parameter | Value |
|---|---|
| Input Voltage | 24 V DC |
| Input Current | 100 mA |
| Maximum Output Current | 2 A |
| Maximum Power | 50 W |
| Supply Voltage (HMI) | 24 V DC |
| Typical Power Consumption | 10 ~ 15 W |
| Item | Parameter |
|---|---|
| Overall Dimensions (Module) | 105 mm (H) × 22.5 mm (W) × 120 mm (D) |
| Overall Dimensions (Panel) | 265 mm (W) × 206 mm (H) × 58 mm (D) |
| Weight (Module) | Approx. 0.2 kg |
| Weight (Panel) | Approx. 1.1 kg |
| Mounting Method | 35 mm DIN rail (module) / Panel mounting (HMI) |
| Terminal Type | Screw terminal |
| Item | Parameter |
|---|---|
| Operating Temperature Range (Module) | -25 ℃ ~ +70 ℃ |
| Operating Temperature Range (Panel) | 0 ℃ ~ +50 ℃ |
| Storage Temperature | -20 ℃ ~ +70 ℃ |
| Front Panel Protection | IP66 |
| Rear Panel Protection | IP20 |
| Relative Humidity | 5 % ~ 95 % (non-condensing) |
| Item | Parameter |
|---|---|
| Display Size | 6.5 inches |
| Display Type | TFT color display |
| Resolution | 640 × 480 pixels (VGA) |
| Touchscreen Type | Resistive (polyester on glass) |
| Backlight | LED |
Serial Ports: 1–2 × RS-232C, RS-422/RS-485
Ethernet Port: 1 × RJ45
Supported Protocols: Modbus, Profibus, etc. (at module level)
Standards Compliance: IEC 61131-2
Certifications: CE, UL, KCC, etc. (depending on version)
Summary
The ABB PP845 3BSE042235R1 is a high-performance HMI/control panel designed for industrial automation. It features 24 V DC power supply, wide operating temperature ranges, IP66 front panel protection, and versatile communication interfaces (serial + Ethernet). Equipped with a 6.5-inch TFT color display and resistive touchscreen, it is well suited for applications requiring reliable human-machine interaction and on-site signal processing.
Inventory//Affordable prices//Excellent quality//Imported with original packaging
===================================================================================================================================================================
First hand source//affordable price//Spot inventory!
•Shipping Port: Xiamen
•Manager: Rhonda•E-mail: sales7@saulplc.com
•Tel/WhatsApp/Wechat: + 86-15359273796
•Ship to you via Fedex/DHL/TNT/UPS/EMS
•Package: Original packing with cartons
