ABB 70EB02C-ES


ABB 70EB02C-ES Product Overview


Product Type: Input Module of the ABB ProControl P13 series, designed for acquiring switching signals from external contactors, push buttons, switches, etc.
Number of Channels: 16 digital inputs (x16), each channel can directly connect to normally open/closed contacts.
Mounting Method: DIN rail mounting, compatible with standard 35 mm rails.

Electrical Parameters

Rated Voltage: 230 V AC (50/60 Hz)

Input Current: ≤ 0.5 A per channel

Isolation Level: Input/output isolation provided by optocouplers or isolation transformers to prevent interference.

Environmental Adaptability

Operating Temperature: -20 °C to +70 °C

Relative Humidity: 5 % to 95 % RH (non-condensing)

Protection Rating: IP20 (for indoor use)

Dimensions/Weight: Approx. 85 mm × 35 mm × 72 mm, weight ~ 0.25 kg

Main Functions

Signal Acquisition: Captures on/off states of contactors, push buttons, limit switches, etc.

Signal Isolation: Provides electrical isolation between input signals and PLC/DCS, enhancing noise immunity.

Signal Conversion: Converts mechanical switch signals into standard digital signals for higher-level systems.

Data Transmission: Transmits digital signals to PLC, DCS, or other control units via the ProControl P13 bus.

Typical Applications

Acquisition of control signals for machine start, stop, and emergency stop.

Monitoring valve, pump, and actuator status in process control systems.

Implementation of safety interlocks and interlocking functions.

Any automation system requiring a large number of discrete switch inputs.

Reference Information Sources

Listed in the ABB ProControl P13 product catalog as “Input Module for Contacts (x16).”

Detailed specifications (rated current, breaking capacity, dimensions, IP rating, etc.) are available in electrical component supplier descriptions.

Further technical details (temperature range, humidity, functional descriptions) can be found in the ABB I/O module series technical manual.

Conclusion

The ABB 70EB02C-ES is a 16-channel digital input module designed for industrial automation systems. Featuring DIN rail mounting, robust electrical isolation, and a wide operating temperature range, it is suitable for machine control, process control, and safety interlock applications.

===================================================================================================================================================================
