Sweden The ABB FPR3203526R1002A is a modular industrial control/inverter product from the ABB PROCONTIC series, widely used in high-reliability automation systems.
Main Functions
Variable Frequency Drive (VFD) and Vector Control:
Provides precise speed control for high-power motors (315 kW, 380 V).
Electronic Protective Relay:
Offers multiple protection mechanisms including overload, short-circuit, and ground fault protection.
Modular I/O and Signal Conversion:
Supports digital, analog, and dedicated signal interfaces; can be used as an I/O card for PLCs, robotic systems, and other automation controllers.
Industrial Network Communication:
Compatible with Profibus, Profinet, EtherNet/IP, and Modbus protocols, enabling data acquisition, process monitoring, and coordinated equipment operation.
Technical Specifications (Overview)
| Item | Parameter | Remarks |
|---|---|---|
| Power | 315 kW | Suitable for large-capacity motors |
| Operating Voltage | 380 V (also available in 24 V DC versions) | Depends on sub-model |
| Frequency Range | 0 – 400 Hz | Vector control |
| Protection Level | IP20 (others optional up to IP65) | Dust and moisture resistance for field environments |
| Operating Temperature | –20 °C to +70 °C | Industrial-grade environmental tolerance |
| Communication Protocols | Profibus, Profinet, EtherNet/IP, Modbus etc. | Multi-protocol compatibility |
| I/O Interfaces | Digital, analog, and dedicated signal interfaces (channel count configurable) | Modular and expandable |
| Protection Functions | Overload, short-circuit, ground fault, etc. | Electronic relay protection |
Application Fields
Industrial Automation Control/Display Units:
Production lines, process monitoring, and data acquisition systems.
Power and Energy Management:
Substations, distribution automation, wind and solar power systems, and other renewable energy applications.
Machine and Robot Control:
Mechanical and automotive manufacturing, robotic systems, and interface modules.
Rail and Intelligent Transportation:
Signaling systems and transportation infrastructure control.
Process Industries:
Chemical, petrochemical, and pharmaceutical process control systems.
Summary
The ABB FPR3203526R1002A combines high power capacity, vector-based motor control, modular I/O, and multi-protocol communication capabilities, making it ideal for applications that demand high reliability and scalable expansion—including industrial automation, energy, power, and transportation sectors.
Different configurations offer various protection ratings and power supply options, allowing users to select models tailored to their specific site requirements.
