ABB HIFG423365R0001 AGIE 625.351.2 PEP.05A Overview

The ABB HIFG423365R0001 AGIE 625.351.2 PEP.05A is an intelligent protection device designed for high-voltage power grids, applicable to 35 kV – 245 kV electrical systems. It integrates multiple protection functions—overcurrent, overvoltage, short-circuit, grounding, distance, and differential protection—and features switching operation, reclosing control, and remote communication capabilities via Modbus RTU and DNP3.0 protocols. The device is commonly used in substations, power plants, and large industrial facilities for power system protection and control.

Main Technical Specifications

Rated Voltage: 35 kV – 245 kV

Rated Current: 630 A

Protection Class: IP67

Operating Temperature: -40 °C ~ +70 °C

Dimensions: 800 mm × 600 mm × 300 mm

Weight: Approx. 200 kg

Supported Communication Protocols: Modbus RTU, DNP3.0

In addition, the same model HIFG423365R0001 is also described as a bus expansion module within the AGIE 625.351.2 series, designed to enhance bus communication capabilities in industrial automation and robotics systems. It is compatible with the AGIE 625.351.2 series and other compatible bus architectures. The module supports expandability, enabling the connection of additional devices or extending communication distances—ideal for applications requiring high-reliability bus communication.

In summary, the HIFG423365R0001 can serve dual purposes:
as an intelligent protection device for high-voltage power networks, or as a bus expansion module in industrial automation systems, depending on its application context within the system.
