Product overview

UFC760BE42-3BHE004573R0042 is a high-performance programmable logic controller (PLC) control board module developed by ABB, specifically designed for Modicon Modbus RTU communication. It provides powerful processing capabilities, rich I/O interfaces, and various communication functions to meet the needs of various industrial automation applications.

Product parameters

Processor: PowerPC 604e, clock speed 333 MHz

Memory: 64 MB SDRAM, expandable up to 256 MB

I/O points: digital quantity I/O: up to 256 points; Analog I/O: up to 32 points

Communication interfaces: RS-232, RS-485, CAN, Ethernet

Working temperature: -20 ° C to 60 ° C

Protection level: IP65

Product specifications

Size: 35 mm x 115 mm x 80 mm

Weight: 0.54 kg

Installation method: DIN rail installation

Power supply voltage: 24 V DC

Series

UFC760BE42-3BHE004573R0042 belongs to ABB's UFC760 series PLC control board module series. This series also includes other models, such as UFC760BE22-3BHE004573R0042 and UFC760BE82-3BHE004573R0042, which have different I/O points and communication functions.

characteristic

High performance: UFC760BE42-3BHE004573R0042 adopts a high-performance processor and high-speed I/O interface, which can meet demanding application requirements.

Reliability: UFC760BE42-3BHE004573R0042 adopts a sturdy and durable design, which can work in harsh environments.

Flexibility: UFC760BE42-3BHE004573R0042 supports multiple programming languages and rich feature libraries to meet various application needs.

Scalability: UFC760BE42-3BHE004573R0042 can expand the number of I/O points and communication functions to meet the needs of applications of different scales.

Role

The main function of UFC760BE42-3BHE004573R0042 is to implement the logic control function of industrial control systems. It can receive sensor signals from on-site devices, process them logically, and output control signals to actuators to control the operation of the equipment.

Purpose

UFC760BE42-3BHE004573R0042 can be used for various industrial automation applications, such as:

Discrete Control: UFC760BE42-3BHE004573R0042 can be used to control discrete control systems such as conveyors, sorting machines, packaging machines, etc.

Process control: UFC760BE42-3BHE004573R0042 can be used to control production processes in industries such as chemical, food, and beverage.

Mechanical Control: UFC760BE42-3BHE004573R0042 can be used to control production equipment in industries such as mechanical manufacturing and automotive manufacturing.

Application area

UFC760BE42-3BHE004573R0042 is widely used in the following fields:

Industrial Automation: UFC760BE42-3BHE004573R0042 is one of the most commonly used PLC control board modules in the field of industrial automation, which can be used for various industrial control applications.

Manufacturing: UFC760BE42-3BHE004573R0042 can be used to control production lines in industries such as automobiles, machinery, and food.

Logistics industry: UFC760BE42-3BHE004573R0042 can be used to control logistics systems such as warehousing and logistics.

Construction industry: UFC760BE42-3BHE004573R0042 can be used to control building systems such as HVAC, lighting, and fire protection.
