This module is a ProcessMaster (PM500 series) I/O module, specifically a 16-channel Voltage Analog Input module, designed for use in ABB's AC 800M high-performance automation controllers within the System 800xA or Compact Control Builder environment.
| Parameter Category | Specification Details |
|---|---|
| Article Number | 3BSE011181R1 |
| Product Name | PM511V16 |
| Module Type | Analog Input Module |
| Number of Channels | 16 channels, individually isolated and configurable. |
| Signal Type | Voltage |
| Input Ranges (Software Selectable per Channel) | • 0 - 5 V DC • 0 - 10 V DC • ±5 V DC • ±10 V DC • 1 - 5 V DC (Supports wire break detection) |
| Resolution | 16-bit (including sign bit) |
| Conversion Rate | 10 ms for all 16 channels. |
| Accuracy (at 25°C/77°F) | ±0.05% of full scale (typical) |
| Input Impedance | > 1 MΩ |
| Common-Mode Rejection (CMR) | > 120 dB at 50/60 Hz |
| Normal-Mode Rejection (NMR) | > 70 dB at 50/60 Hz |
| Isolation | Channel-to-Channel: 500 V AC (Continuous) Channel-to-Bus: 1500 V AC (Continuous) |
| Open Circuit Detection (Wire Break) | Supported for the 1-5 V range. An input value below a defined threshold (e.g., < 0.8 V) can be flagged as a wire break error. |
| Connection | Via a removable front connector (often a TB521 or similar), which connects to the internal X1 and X2 connectors on the module. |
| Power Supply | Voltage: +24 V DC (from the baseplate) Power Consumption: Typically 1.2 W (0.05 A @ 24V) |
| Status Indicators (LEDs) | • OK (Green): Module operational. • ACT (Green): Module is active and communicating. • EX (Red): Module error or fault. |
| Operating Temperature | 0 to +60 °C (+32 to +140 °F) |
| Storage Temperature | -40 to +70 °C (-40 to +158 °F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Emissions & Immunity | Complies with standards such as EN 61326-1 for industrial environments. Designed for high noise immunity. |
| Mounting | Mounts on a standard UNITELIUM baseplate (e.g., FI810F, etc.) which provides the connection to the controller's Profibus DP network and power. |
| Weight | Approximately 0.3 kg (0.66 lbs) |
High Density: Provides 16 analog input points in a single module slot, saving space in the PLC rack.
Flexible Configuration: Each channel can be individually configured for different voltage ranges and scaling within the control system engineering software (e.g., Control Builder M).
High Accuracy and Resolution: The 16-bit resolution and 0.05% accuracy make it suitable for precise measurement applications.
Excellent Isolation: High channel-to-channel and channel-to-bus isolation protects the system from ground loops and electrical noise, which is critical in industrial environments.
Diagnostics: Includes comprehensive diagnostics like wire break detection (for 1-5V range), over-range detection, and module health status via LEDs.
The PM511V16 is used to interface with a wide variety of voltage-output field devices in process and factory automation, including:
Pressure, level, and flow transmitters (with voltage output)
Potentiometers and position sensors
Signal conditioners and isolators
Any analog sensor providing a 0-10V, ±10V, or 1-5V signal.
Inventory//Affordable prices//Excellent quality//Imported with original packaging
===================================================================================================================================================================
First hand source//affordable price//Spot inventory!
•Shipping Port: Xiamen
•Manager: Rhonda•E-mail: sales7@saulplc.com
•Tel/WhatsApp/Wechat: + 86-15359273796
•Ship to you via Fedex/DHL/TNT/UPS/EMS
•Package: Original packing with cartons
