ABB 3BHB003688R0101

Quick Identification Summary

Manufacturer: ABB

Product Type: CI854A - PROFIBUS DP/V1 Master Interface Module

Order Number: 3BHB003688R0101

Function: This module allows an AC 800M controller to act as a Master on a PROFIBUS DP and PROFIBUS PA network.

Detailed Technical Parameters

1. Primary Function & Communication

Interface Type: PROFIBUS (Process Field Bus)

Protocols Supported: PROFIBUS DP (Decentralized Peripherals) and PROFIBUS PA (Process Automation) via a segment coupler.

Role: Master (Class 1)

Standard: Fully compliant with EN 50170 Vol. 2 / IEC 61158 / IEC 61784-1 (PROFIBUS DP).

Data Transfer Rate: Automatically detects and configures baud rates from 9.6 kbit/s up to 12 Mbit/s.

2. Physical & Electrical Specifications

Connector: 1 x 9-pin D-sub female connector (following the standard PROFIBUS pinout).

Isolation: Galvanic isolation between the module's internal electronics and the PROFIBUS network.

Termination: Requires an external bus terminator (usually switched on the connector or a separate plug) to be enabled at both ends of the PROFIBUS cable segment.

3. Performance & Capacity

Number of Slaves: Supports up to 96 slave devices on the network.

I/O Capacity: Can handle up to 1440 bytes of input data and 1440 bytes of output data per scan cycle.

Diagnostics: Extensive diagnostic capabilities for the module itself and the connected slaves, accessible through the controller's engineering tool (Control Builder).

4. Integration & Software

Compatible Controller: Designed for use in the AC 800M High Performance (PM856, PM860, etc.) and Compact Performance (PM851) controller racks.

Required Software: Configuration and programming are done using ABB's Control Builder M (often referred to as CBM) engineering tool.

GSD Files: Uses standard PROFIBUS Generic Station Description (GSD) files to integrate and configure slave devices from any manufacturer.

5. Mechanical & Environmental

Module Type: Single-width, hot-swappable module (when used in a supported redundant system configuration).

Operating Temperature: 0 to +60 °C (32 to 140 °F)

Storage Temperature: -40 to +70 °C (-40 to 158 °F)

Relative Humidity: 5 - 95% (non-condensing)

6. LEDs (Front Panel Indicators)

The module features status LEDs that provide critical operational information:

RUN (Green): Indicates the module is operating correctly.

ERR (Red): Indicates a hardware or firmware error.

COM (Yellow): Flashes during data communication on the PROFIBUS network.

MS (Yellow): Indicates the module is the active master in a redundant system setup.

===================================================================================================================================================================
