Sweden | Parameter Category | Specification |
|---|---|
| Manufacturer | ABB |
| Product Type | Rack Interface Module (RIM) |
| Series/Platform | Advant Controller 400 / AC 400 |
| Compatible System | MasterPiece 200 / 2001 |
| Model Number | 3BHB030310R0001 |
| Article Number | 3BHB 030310 R0001 |
| Rack Type | LH30 (Large Horizontal Rack, 30 slots) |
| Primary Function | Provides the backplane bus (e.g., MODBUS, MATBUS) and power distribution for all other modules installed in the rack. |
| Number of Slots | Provides connectivity for up to 30 modules (including itself). |
| Slot Position | Must be installed in a fixed, designated slot (typically slot 1) within the LH30 rack. |
| Power Supply | Does not generate power itself. It distributes power from a separate Power Supply Module (e.g., 3BSE002512R1) connected to the rack's backplane. |
| Backplane Bus | Facilitates the internal MODBUS and MATBUS communication between the CPU, I/O, and communication modules in the rack. |
| Communication | Acts as the gateway for the rack to communicate with other racks and the higher-level control network via the system buses. |
| Operating Temperature | 0 to +60 °C (32 to 140 °F) |
| Storage Temperature | -40 to +70 °C (-40 to 158 °F) |
| Relative Humidity | 5 - 95% (non-condensing) |
| Vibration | Designed to withstand industrial vibration levels as per relevant standards (e.g., IEC 60068-2-6). |
Backplane Core: It is the central nervous system of the LH30 rack. It contains the circuitry for the internal data highways (MODBUS for I/O data, MATBUS for inter-processor communication) and the power distribution lines.
System Integration: It allows all modules in the rack (CPU, DI/DO, AI/AO, Communication, etc.) to function as a cohesive unit and communicate with the broader MasterPiece 200 system.
Physical Interface: It provides the physical connectors and electrical pathways that modules plug into.
This module is used as a core component in large, distributed process automation systems, such as:
Oil & Gas refineries
Chemical and pharmaceutical plants
Pulp and paper mills
Power generation and distribution systems
Metal and mining industries
HBFGDAAHNDCCBNA11G: This is the Ordering Code or Product Code. It's a combination of letters that defines all the specific hardware and software options. Decoding it:
| Code Segment | Meaning | Description for this Model (HBFGDAAHNDCCBNA11G) |
|---|---|---|
| HB | Hardware Basic Platform | Standard hardware platform for REF615. |
| F | Enclosure Type | NEMA 4X (IP66) flush-mounted case. This is a rugged, weatherproof and dust-tight enclosure suitable for outdoor use, common in North American applications. |
| G | User Interface | Graphical display with keypad and LED indicators. This is the high-resolution, intuitive interface. |
| D | Communication | 2x Ethernet (RJ45) + 1x RS485. Provides modern, high-speed communication for SCADA systems. |
| A | Software Language | International English (standard). |
| A | Protection Functions | Standard protection set for the REF615. This includes overcurrent, earth-fault, breaker failure, etc. |
| H | Measurement | Basic measurement functions (e.g., V, I, P, Q, pf, frequency, harmonics). |
| N | Breaker Control | One-shot ARC (Automatic Reclosing). A critical function for overhead line feeders to automatically attempt to re-close the breaker after a temporary fault. |
| D | RTD Inputs | No RTD (Resistance Temperature Detector) modules. |
| C | Analog Outputs | No analog output modules. |
| C | Binary Inputs/Outputs | Standard number of I/O (Typically 8 Binary Inputs + 5 Binary Outputs). |
| B | Power Supply | 48-125 V DC / 48-110 V AC (This matches the "1G" prefix). |
| NA | Regional Application | North American market. This signifies firmware and standards compliance (like ANSI device numbers) tailored for the US, Canada, and Mexico. |
| 1 | Documentation Language | English. |
| 1 | Package Quantity | Single unit. |
| G | Accessories | No additional accessories (shipped standard without extra items like CT shorting blocks). |
Primary Function: Protecting electrical feeders (incoming or outgoing lines) in substations and industrial plants.
Key Protections: Overcurrent (50/51, 50N/51N), Earth-Fault (50N/51N, 67N), Automatic Reclosing (79), Breaker Failure (50BF), and Thermal Overload (49).
Communication: Dual Ethernet ports for integration into modern IEC 61850-based substation automation systems.
Environment: Built in a robust NEMA 4X enclosure for demanding environments.
Market: Specifically designed for North American standards and practices.
Inventory//Affordable prices//Excellent quality//Imported with original packaging
===================================================================================================================================================================
First hand source//affordable price//Spot inventory!
•Shipping Port: Xiamen
•Manager: Rhonda•E-mail: sales7@saulplc.com
•Tel/WhatsApp/Wechat: + 86-15359273796
•Ship to you via Fedex/DHL/TNT/UPS/EMS
•Package: Original packing with cartons
