This product is a CI854-ETH communication interface module, which is a critical component within ABB's IndustrialIT Extended Automation System 800xA and AC 800M controller family.
Product Type: Communication Interface Module
Primary Function: To provide a high-speed, redundant Ethernet (TCP/IP) network connection between the AC 800M controller and the higher-level 800xA system or other client applications.
Key Feature: It is a redundant module, meaning it is always used in pairs to ensure maximum availability and no single point of failure in the network connection.
| Category | Specification |
|---|---|
| Manufacturer / Model | ABB CI854-ETH (3BHB043805R0001 is the order code) |
| Product Line | IndustrialIT Extended Automation System 800xA |
| Controller Compatibility | AC 800M (e.g., PM861, PM851, etc.) |
| Primary Protocol | Ethernet (TCP/IP) for client/server communication. |
| Network Standard | IEEE 802.3 (10/100 Mbps) |
| Connector Type | 2 x RJ45 ports (for the two redundant channels) |
| Data Transfer Rate | 10 Mbps or 100 Mbps, auto-negotiating. |
| Redundancy | Yes, built-in. The module supports redundant operation (pairing) for fault-tolerant communication. |
| Isolation | 500 V AC RMS (galvanic isolation) |
| Power Supply | +5 V DC (supplied directly from the AC 800M controller's base unit via the internal bus). |
| Power Consumption | Typical: 450 mW (0.45 W) |
| Status Indicators (LEDs) | • RUN (Green): Operating status • ERR (Red): Error/fault status • COM (Yellow): Data transmission activity • L/A (Green/Yellow): Link status (Green) and Activity (Yellow) for each port. |
| Operating Temperature | 0 °C to +55 °C (+32 °F to +131 °F) |
| Storage Temperature | -40 °C to +70 °C (-40 °F to +158 °F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Altitude | Up to 2000 meters (6560 feet) above sea level without derating. |
| Safety Standards | UL 508 (Industrial Control Equipment) |
| EMC Immunity | Complies with EN 61000-6-2 (Industrial Immunity Standard) |
| EMC Emissions | Complies with EN 61000-6-4 (Industrial Emissions Standard) |
| Dimensions (H x W x D) | Approx. 128 mm x 46 mm x 119 mm (fits within an AC 800M unit) |
| Mounting | Plugs directly into a dedicated slot on the AC 800M controller's base unit (e.g., TB811, TB821, or TB851). |
The CI854 module acts as the physical and data link layer interface for the controller's communication with the plant network. Its main roles are:
Network Gateway: It is the primary gateway for the AC 800M controller to communicate with the 800xA Operator Workplace, Engineering Workplace, and other nodes on the control network.
Redundancy: When two CI854 modules are installed in a redundant configuration, if the primary module fails, the secondary module takes over seamlessly without interrupting the control process or losing data.
Protocol Handling: It handles the low-level Ethernet protocols, allowing the controller's CPU to focus on executing the control logic.
Connecting an AC 800M controller to an 800xA system network.
Enabling communication with third-party systems (e.g., SCADA, MES) via standard TCP/IP.
Creating a fault-tolerant network architecture in critical processes like oil & gas, power generation, chemical, and pharmaceutical industries.
Inventory//Affordable prices//Excellent quality//Imported with original packaging
===================================================================================================================================================================
First hand source//affordable price//Spot inventory!
•Shipping Port: Xiamen
•Manager: Rhonda•E-mail: sales7@saulplc.com
•Tel/WhatsApp/Wechat: + 86-15359273796
•Ship to you via Fedex/DHL/TNT/UPS/EMS
•Package: Original packing with cartons
