ABB PE1315A Product Overview


DC Power Supply Module

Output: 24 V DC, maximum current 2.5 A, power ≈ 60 W

Input: 100-240 V AC (50/60 Hz) or 120-300 V DC, voltage adjustable ±10%

Efficiency: > 85% (typical); ripple and noise < 1% (peak-to-peak)

Operating Temperature: -25 °C to +60 °C

Protection Rating: IP20, DIN-rail mounting (TS35)

Protection Features: Overcurrent protection (OCP) and short-circuit protection (SCP); compliant with IEC/EN 60950-1 (CE, UL, CSA, TÜV certified)

Photoelectric Isolation Pulse Amplifier

Uses photoelectric isolation technology to enhance input/output signal anti-interference capability and safety.

Main function: amplify input pulse signals with an output voltage range of 5-24 V and current limit ≈ 13 mA.

Supports multi-channel design (A, B, strobe) and is suitable for radar, laser, communication systems, and other industrial automation applications.

Input/Output Module (I/O Module)

Power Supply: 24 V DC ± 20%

Maximum Input Current: 5 mA (single-ended/differential)

Provides 16 digital input channels and 16 relay output channels.

Supports Ethernet, serial, and other communication interfaces with high-speed processing and remote diagnostics capabilities.




Compact Inverter

Part of ABB’s motor drive series, designed for small- and medium-power three-phase asynchronous motors, providing V/F open-loop vector control.

Features a book-type compact design to save cabinet space.

Compliant with IEC 61800-3 environmental adaptability standards, suitable for harsh industrial environments.
