ABB P3LB HENF209568R0001 Overview
The ABB P3LB HENF209568R0001 is an industrial automation control module (also referred to as a control board or circuit board) manufactured by ABB. It is commonly used in DCS, PLC, and process control systems.
Key Features
| Item | Description |
|---|---|
| Product Positioning | High-performance process automation/control module, part of the P3LB series memory/control unit family |
| Communication Interfaces | Supports multiple industrial communication protocols, including Ethernet, CANopen, PROFIBUS, RS-485, and Modbus TCP/IP/RTU |
| Operating Temperature | –25 °C to +60 °C (some sources specify –25 °C to +55 °C) |
| Power Consumption | ≤ 25 W (some documents list up to 120 W depending on configuration) |
| Dimensions / Weight | Approx. 142.4 mm × 101.6 mm × 51.8 mm; weight ≈ 0.25 kg |
| Functions | – Executes complex control algorithms (e.g., temperature, flow, speed) – Acquires and processes analog/digital signals (8 analog inputs) – Supports signal conditioning such as linearization, filtering, and limit setting |
| Operating Environment | Designed for industrial sites and harsh environments, rated IP65 for protection |
| Programming Compatibility | Complies with IEC 61131-3 standards (supports Ladder Diagram, Structured Text, etc.) |
Typical Application Scenarios
Process Control: Real-time regulation of parameters such as temperature, pressure, and flow in continuous-process industries including chemical, petroleum, and metallurgy sectors.
Machine Automation: Used in CNC machines, packaging lines, and other equipment requiring high-speed data acquisition and closed-loop control.
System Integration: Serves as a DCS/PLC sub-module to provide extended memory or dedicated I/O functionality.
Summary
The ABB P3LB HENF209568R0001 is a versatile, multi-protocol, and highly reliable control board designed for demanding industrial automation systems that require high-precision signal acquisition and sophisticated control algorithms. Its compact design, low power consumption, and wide communication compatibility ensure stable operation across a variety of industrial environments.
