ABB PILA HENF209556R0002 Product Overview
| Item | Key Features | Remarks |
|---|---|---|
| Product Series | PILA (ABB Industrial Automation Series) | Suitable for various automation, process control, and power applications |
| Product Form | 1️⃣ Analog Output / Pressure Transmitter 2️⃣ PLC Module 3️⃣ Power / Energy Module (variants from different suppliers) |
The same model may correspond to different function modules depending on the distribution channel |
| Key Technical Parameters | - Measurement range: 0-100 bar (Pressure Transmitter) - Output signal: 4-20 mA DC (Transmitter) - Rated voltage: 12-35 V DC (Transmitter) - Power consumption: < 2 W (Transmitter) - Operating temperature: -40 °C ~ +120 °C - Protection class: IP67 - Material: Stainless Steel |
Suitable for harsh industrial environments |
| Analog Output Module (Common Specs) | - Channels: 8 - Output range: 0-10 V - Resolution: 12 bit - Connector: 96-pin D-Sub - Dimensions: 100 × 100 × 40 mm - Weight: 0.5 kg |
For analog output in PLC systems |
| PLC Module (High-Performance Version) | - CPU: Advanced Microcontroller, 100 MHz - Memory: 64 MB RAM + 128 MB Flash - Digital I/O: 32 DI + 32 DO - Communication: RS-485, Ethernet - Dimensions: approx. 100 × 100 × 35 mm |
Designed for complex control logic, data acquisition, and remote monitoring |
| Power / Energy Module (High-Power Type) | - Input voltage: 115 V / 230 V AC - Output voltage: 48 V DC - Output current: 43.8 A (≈ 2094 W) - Efficiency: 96 % - Dimensions: 305 × 175 × 75 mm - Weight: 5.1 kg |
Suitable for powering high-power industrial equipment |
| Typical Applications | - Industrial process control (temperature, pressure, flow, etc.) - Power distribution and monitoring - Robotics and discrete automation - Data centers and medical equipment requiring high power quality - Analog signal output and conversion for PLC systems |
Compatible with ABB PLC, DCS, and VFD platforms |
| Certifications / Standards | - IEC 60068-2-6 - IECEx ia IIC T6 - ATEX II 1G Ex ia IIC T6 Gb - CSA C22.2 No.157A-C01917 |
Compliant with international safety and explosion-proof standards |
Key Highlights
High Reliability:
With IP67 protection, a wide temperature range, and a stainless-steel enclosure, the PILA HENF209556R0002 ensures long-term stable operation even in harsh industrial environments.
Flexible Interfaces:
Offers multiple communication options, including D-Sub, Ethernet, and RS-485, facilitating integration with ABB and third-party automation systems.
Wide Applicability:
Covers a broad range of industrial fields—from process control to high-power supply—serving sectors such as power, manufacturing, transportation, and data centers.
