ABB ICSA04B5 & FPR3341501R1042 Overview
| Item | Description | Details |
|---|---|---|
| Product Series | Procontic CS 31 Analog I/O Remote Unit | Part of ABB’s Distributed Control System (DCS) series, designed for field analog signal acquisition and output. |
| Model Reference | ICSA04B5 → Module model FPR3341501R1042 → 24 V DC analog output unit |
FPR3341501R1042 is the 24 V DC version of the analog output unit in the ICSA04B5 series. |
| Power Supply Voltage | 24 V DC (also available in 120 V and 230 V versions) | Other variants include FPR3341501R0044 (120 V) and FPR3341501R0046 (230 V). |
| Power Consumption | 5 W (24 V DC version) | The unit operates at approximately 5 W when powered by 24 V DC. |
| Function | • Analog signal output (0-10 V, 4-20 mA, etc.) • Remote installation with communication via Procontic CS 31 bus |
Suitable for process control, instrumentation signal adjustment, and similar applications. |
| Interface | Standard analog output terminals (screw or clamp) with matching power terminals | Mechanically and electrically compatible with other ABB I/O modules for easy field expansion. |
| Applicable Systems | ABB Procontic CS 31, Procontic CS 31 I/O Network, DCS systems | Seamlessly integrates with ABB PLC and DCS controllers. |
| Key Advantages | • Remote field installation reduces wiring complexity • Multiple voltage options for diverse power environments • Reliable industrial-grade design suitable for harsh environments |
Example Applications
-
Process Control:
In chemical or oil refining plants, the ICSA04B5-24 V DC module outputs control signals (e.g., valve position) from field sensors to actuators. -
Instrumentation Adjustment:
In power generation or water treatment systems, it provides 4-20 mA or 0-10 V analog outputs for precise control of regulating valves, frequency converters, and other devices. -
Remote Monitoring:
When connected via the Procontic CS 31 bus, analog output signals can be transmitted back to the supervisory control system for centralized monitoring and historical data recording.
Summary
The ABB ICSA04B5 is an analog I/O remote unit from the Procontic CS 31 series, while the FPR3341501R1042 is its 24 V DC, 5 W analog output version, ideal for industrial control systems requiring remote analog signal output at field sites.
