Model：ABB PFXC141 industrial component

Brand: ABB 2025-10-17
Price range (USD): 2000-4000
Country: Sweden
Parameter: Model & Part Number： PFXC141 (3BSE029997R0001 / 3BSE029997R1)
Primary Function： Junction Box / Industrial Control Module
Application System： PMG100 Thickness Gauge systems; Industrial Automation & Tension Control
Processor & Memory： 1GHz processor, 512MB RAM, 8GB flash memory

Contact Me

Xiamen Xingruijia Import and Export Co., Ltd. has been specializing in the sales of industrial control equipment spare parts for 20 years. For more ABB models, please refer to the product list . If you need other brands or models, please contact us. We have a variety of brands and models in stock, and we can purchase difficult to order models for you. We look forward to your inquiry!!!

First hand source//affordable price//Spot inventory!

•Shipping Port: Xiamen

•Manager: Rhonda

•E-mail: sales7@saulplc.com

•Tel/WhatsApp/Wechat: + 86-15359273796

•Ship to you via Fedex/DHL/TNT/UPS/EMS

•Package: Original packing with cartons

==============================================================================================================================================

ABB PFXC141

The ABB PFXC141 is a versatile industrial component that functions as a junction box or industrial control module, primarily within ABB's force and thickness measurement systems. Here are its detailed technical specifications:

ABB PFXC141 (Part No. 3BSE029997R1) Overview

Item	Description	Reference
Product Category	Junction Box / Tension / Force-Torque Sensor Module, part of the ABB PFX series field control modules
Main Functions	- Designed for measuring and amplifying material tension, force, and torque. - Provides power supply, signal conditioning, and multiple communication interfaces; supports industrial protocols such as Modbus RTU. - Compatible with ABB 800xA, DCS, PLC, and other automation systems.
Technical Specifications	- Rated load: 0.1 – 1.0 kN (22 – 225 lb) - Extended load: 0.15 – 1.5 kN (33 – 337 lb) - Permissible load: 0.3 – 5.0 kN (67 – 1125 lb) - Measuring range: Force 0 – 500 N, Torque 0 – 50 Nm - Outputs: 1 × Analog (V/mA) + 1 × Digital Output, 1 × Digital Input - Power supply: 24 V DC (some variants rated at 12 V DC) - Protection class: IP65, suitable for harsh industrial environments - Dimensions / Weight: Approx. 100 × 75 × 35 mm; Net ≈ 0.25 kg (Gross ≈ 0.3 kg)
Applications	- Continuous production lines requiring tension control, such as paper-making, metallurgy, and textile industries. - Laboratory and field testing for force/torque measurement. - Process control, robotics, testing, and monitoring in automation systems.
Installation and Usage Notes	1. Inspection: Ensure the junction box is intact and free of visible damage. 2. Sensor connection: Connect strain gauge or pressure sensors to the corresponding terminals. 3. Power and communication: Connect 24 V DC power supply and configure Modbus or other communication ports. 4. Calibration: Perform zero-point calibration and range setting according to site conditions. 5. Monitoring: Use the supervisory system to read real-time force/torque data for closed-loop control.
Compatible Systems	ABB 800xA, ABB MasterPiece 200 / AC450, Advant OCS, MOD 300, PLC I/O modules, etc.

Key Summary
The ABB PFXC141 is an industrial junction box designed for tension, force, and torque measurement, integrating power supply, signal conditioning, and multi-channel communication capabilities. Built to operate reliably in harsh industrial environments (IP65), it offers wide measurement ranges and versatile interface options, making it suitable for paper, metallurgy, robotics, and other precision tension or torque control applications.

When ordering, note the part number 3BSE029997R1 and ensure correct wiring and configuration based on the site’s power supply (24 V DC) and communication protocol (such as Modbus RTU).
ABB PFXC141
