ABB3ASC25H209 DATX110 I/O module

ABB3ASC25H209 DATX110 I/O module

 ABB 3ASC25H209 DATX110

Model:ABB3ASC25H209 DATX110 I/O module

  • Brand: ABB 2025-10-20
  • Price range (USD): 2000-4000
  • Country: Sweden
  • Parameter: Analog Input Range: −10 V to +10 V

    PWM Output Frequency: 1 kHz to 100 kHz

    Operating Temperature: −20 °C to +55 °C

    Protection Rating: IP67 (also available in IP20 versions)

    Dimensions / Weight: Approx. 90 mm × 45 mm × 25 mm; weight ≈ 150 g

Xiamen Xingruijia Import and Export Co., Ltd. has been specializing in the sales of industrial control equipment spare parts for 20 years. For more ABB models, please refer to the product list . If you need other brands or models, please contact us. We have a variety of brands and models in stock, and we can purchase difficult to order models for you. We look forward to your inquiry!!!

First hand source//affordable price//Spot inventory!

•Shipping Port: Xiamen

•Manager: Rhonda

•E-mail: sales7@saulplc.com

•Tel/WhatsApp/Wechat: + 86-15359273796

•Ship to you via Fedex/DHL/TNT/UPS/EMS

•Package: Original packing with cartons

==============================================================================================================================================


BB 3ASC25H209 DATX110 OverviewA

The ABB 3ASC25H209 DATX110 is a high-performance I/O module (also referred to as a control board or terminal block) designed by ABB for industrial automation systems. It is commonly used in AC800M, DCS, and medium-voltage AC drive systems. The following summarizes its core specifications and features.


ABB 3ASC25H209 DATX110

Main Technical Specifications

Rated Voltage: 24 V DC (some documentation also lists 220 V, depending on wiring configuration)

Rated Current: 2.5 A

I/O Points: 25 points (including digital input/output and analog input/output)

Counting Frequency: 50 kHz

Analog Input Range: −10 V to +10 V

PWM Output Frequency: 1 kHz to 100 kHz

Operating Temperature: −20 °C to +55 °C

Protection Rating: IP67 (also available in IP20 versions)

Dimensions / Weight: Approx. 90 mm × 45 mm × 25 mm; weight ≈ 150 g


Functional Features

Modular Design: Easily expandable; supports DIN-rail mounting for convenient on-site maintenance.

Multiple I/O Types: Provides digital, analog, and PWM output channels to meet diverse signal processing needs.

Communication Interfaces: Supports Ethernet, RS-485 (selected models), and PROFIBUS DP, enabling seamless integration with ABB AC800M controllers or other DCS systems.

Protection & Reliability: Features IP67 protection, a wide operating temperature range, and short-circuit/polarity protection, making it suitable for harsh industrial environments.

Diagnostic Capability: Built-in fault diagnostics allow real-time module status monitoring through the control system.


Typical Application Scenarios

Manufacturing: Signal acquisition and control for conveyors, pumps, fans, compressors, and other machinery.

Energy & Power: I/O interfacing for power plants and variable-speed drive systems.

Process Control: Field instrument connectivity in chemical, metallurgical, and oil & gas industries.

Building & Transportation: Monitoring and control in building automation and traffic infrastructure systems.


Product Positioning and Advantages

As the core I/O terminal block of ABB’s DATX 110 series, it is fully compatible with ABB AC800M, ACS300 drives, and DCS systems, providing a unified hardware platform that simplifies system integration and reduces costs.

Its high-speed counting (50 kHz) and wide analog input range enable accurate processing of high-frequency pulse and precision analog signals.

The compact design (approx. 90 × 45 mm) makes it ideal for installations in space-constrained control cabinets while maintaining efficient heat dissipation.


Summary

The ABB 3ASC25H209 DATX110 is a high-performance industrial I/O module featuring rich digital/analog channels, strong communication compatibility, and robust protection. It is ideally suited for automation systems that demand high reliability, precise signal processing, and fast response in demanding industrial environments.
