ABB TP854 Overview
The ABB TP854 is a communication interface base (backplane) developed by ABB for its industrial automation systems, particularly the AC 800M / S800 series. It is primarily used for mounting and supporting the CI854 series fieldbus communication modules (such as CI854, CI854A, and CI854B), enabling reliable PROFIBUS DP (or DP-V1) fieldbus connectivity.
Key Functions
-
Provides mechanical support and electrical connection interface for CI854 communication modules.
-
Supports various fieldbus protocols such as PROFIBUS DP/DP-V1 and FOUNDATION Fieldbus, enabling high-speed data exchange between controllers, field I/O, and remote I/O systems.
-
Includes termination units and terminal resistors to ensure signal integrity and noise immunity across the bus network.
Main Technical Specifications (Typical Values)
| Parameter | Specification |
|---|---|
| Operating Voltage | 24 V DC |
| Rated Current | 4 A |
| Dimensions | Approx. 84 mm × 68 mm × 30 mm (may vary slightly by model) |
| Operating Temperature | -25 °C to +70 °C |
| Storage Temperature | -40 °C to +85 °C |
| Weight | Approx. 120 g (compact and lightweight) |
| Certifications | CE, UL, and other international safety standards |
Typical Application Scenarios
-
Process Control and Discrete Manufacturing: Serves as a communication bridge between controllers and field devices in large-scale automation systems.
-
Remote I/O and Fieldbus Expansion: Connects distributed sensors and actuators through CI854 modules to enable decentralized control architectures.
-
System Redundancy and Reliability Enhancement: Can be paired with dual CI854 modules to achieve primary/backup redundancy, improving system availability.
Summary
In short, the ABB TP854 is a dedicated base plate designed for ABB fieldbus communication modules. It provides robust mechanical support and reliable electrical connectivity, making it an essential component in building high-reliability industrial automation networks.
