ABB FI830F 3BDH000032R1 Overview
The ABB FI830F 3BDH000032R1 is a Profibus-DP fieldbus module from ABB’s Distributed Control System (DCS) series. It is widely used in industrial automation systems to enable high-speed and reliable data exchange between field I/O devices and upper-level controllers such as PLCs and SCADA systems.
.jpg)
Main Functions and Application Scenarios
| Function | Description |
|---|---|
| Fieldbus Communication | Supports the Profibus-DP V1 protocol, providing real-time data transmission between distributed I/O and controllers. |
| Configurable I/O | Can be configured for digital input/output, analog input/output, and other channel types as required. |
| High Reliability | Offers strong anti-interference capability and IP40 protection rating, suitable for harsh industrial environments. |
| Multi-industry Compatibility | Commonly used in power, petrochemical, machinery manufacturing, building automation, and transportation systems for device monitoring and control. |
Technical Specifications (Model: FI830F-3BDH000032R1)
| Item | Parameter |
|---|---|
| Product Model | FI830F (Part No. 3BDH000032R1) |
| Communication Protocol | Profibus-DP V1 |
| Power Supply | 24 V DC |
| Operating Temperature | –25 °C to +60 °C |
| Protection Rating | IP40 |
| Dimensions | Approx. 119 mm × 35 mm × 124 mm |
| Weight | Approx. 0.2 kg |
| Output Channels | Configurable; typically up to 132 configurable ports depending on setup |
| Compatible Systems | ABB S800 I/O System, AC 800F series, and others |
Typical Usage
Hardware Installation:
Install the module on a panel or rack following ABB’s manual, ensuring that the power supply and wiring comply with IEC standards.
Parameter Configuration:
Use ABB’s configuration software (e.g., Automation Builder) to define I/O types, addresses, and diagnostic parameters.
Network Integration:
Connect the module to a Profibus-DP master (PLC or DCS controller). After configuring the network topology, real-time data acquisition and control can be performed seamlessly.
Summary
The ABB FI830F 3BDH000032R1 is a high-reliability Profibus-DP fieldbus module offering flexible I/O configuration, wide operating temperature range, and industrial-grade protection. It is ideally suited for industrial environments requiring precise data acquisition and distributed control.
