ABB 3BHE009017R0102 Overview
The ABB 3BHE009017R0102 belongs to the ABB XVC724BE102 series of VLSCD (Safety PLC) modules, widely used in AC 500 / AC 800M control systems for safety control and I/O expansion.
Main Functions and Applications
Safety Control:
Complies with safety standards such as IEC 61508, SIL 3, and PL e, supporting safety logic for emergency shutdowns, fault diagnostics, and safe process control.
I/O Interfaces:
Provides 24 digital inputs, 16 digital outputs, 2 analog inputs, 2 analog outputs, and an RS-485 communication port, supporting connection with a wide range of field devices.
Communication:
Supports multiple industrial networks including PROFIBUS DP, Ethernet, and RS-232/RS-485, enabling seamless integration with higher-level systems or other ABB controllers.
Typical Industries:
Suitable for food processing, automotive manufacturing, packaging, printing, textile, chemical, and oil & gas industries requiring reliable safety monitoring and process control.
Technical Specifications (Common Parameters)
| Parameter | Description |
|---|---|
| Model | XVC724BE102 (Stock No. 3BHE009017R0102) |
| Power Supply | 24 V DC, power consumption < 2 W (some sources list up to 5 W) |
| Operating Temperature | -20 °C to 55 °C (or -20 °C to 70 °C per some documentation) |
| Protection Class | IP20 |
| Dimensions | Approx. 100 mm × 50 mm × 20 mm (DIN-rail mounted) |
| Weight | Approx. 0.3 – 0.5 kg |
| Interfaces | 2 × RS-485, 1 × isolated interface, digital/analog I/O, Ethernet |
| Certifications | CE, RoHS, IEC 61508, IEC 61131-6 |
Typical Use Cases
Safety PLC:
Serves as a master or slave module in production lines requiring SIL 3-level safety protection, handling safety logic and fault monitoring.
Process Control:
Exchanges data with sensors and actuators via analog I/O for real-time measurement and control of process variables such as temperature, pressure, and flow.
System Integration:
Integrates seamlessly with ABB AC 500 and AC 800M controllers and PROFIBUS/Ethernet networks, supporting remote configuration and maintenance.
Summary
The ABB 3BHE009017R0102 (XVC724BE102) is a high-reliability safety I/O module designed for industrial automation systems.
It supports digital/analog signal acquisition, multi-protocol communication, and SIL 3-level safety control, making it ideal for high-safety manufacturing and process-industry applications..jpg)
