ABB UUD148AE02

ABB UUD148AE02 is a high-performance I/O (Input/Output) module designed by ABB for industrial automation systems, commonly used with the ABB AC 800M / AC 800PEC controller series. Its main technical features are as follows:

Module Functions

8 channels of 16-bit analog inputs (±10 V, 0-10 V, 4-20 mA) with a sampling rate of approximately 10 samples per second.

4 analog output channels, supporting both voltage and current signals.

Equipped with digital input/output channels for discrete signal control.

Built-in output contact monitoring, allowing readback and detection of the actual state of each output channel, achieving high-coverage fault diagnostics.

Electrical Specifications

Operating voltage: 24 V DC, operating current ≤ 1 A, power consumption approx. 1.8 W.

Input current: 250 mA, output current: 1 A.

Isolation voltage: 1500 V, compliant with IEC 61131-2 and SIL2 safety standards.

Environmental & Mechanical Specifications

Operating temperature range: –20 °C to +70 °C (some versions –40 °C to +85 °C); protection class IP20–IP67.

Dimensions: approx. 120 mm × 80 mm × 30 mm; weight: approx. 0.5 kg.

DIN-rail mounting, compatible with standard 35 mm rails; recommended module spacing ≥ 20 mm for proper heat dissipation.

Communication & Diagnostics

Supports industrial fieldbuses such as RS-485, Ethernet, PROFIBUS (via GSDML), and DeviceNet (via EDS).

Parameters can be configured using ABB Control Builder, Automation Builder, STEP 7, TIA Portal, and other engineering software.

Supports remote diagnostics, self-testing, and automatic recovery, reducing operation and maintenance costs.

Application Areas

Suitable for manufacturing, energy, chemical processing, water treatment, and other scenarios requiring high-precision analog signal acquisition and control.

Commonly used in power system monitoring, process control, sensor data acquisition, and actuator control.

In summary, the UUD148AE02 integrates high-precision analog I/O, digital I/O, powerful self-diagnostics, and remote maintenance capabilities, making it a reliable and widely used I/O solution within ABB’s modular control systems.
